General casing position rules:

A external: the distance between the end of the casing and the

PIN is as short as possible, but remember that the casing must

not be wrapped around the PIN, which will cause empty welding phenomenon.

B Interior: A infinity wall fit, flat paste BOBBIN about 1/2L length

B with the side wall, the casing must be in the stop wall.

The width and material of the margin tape can not be replaced arbitrarily, because the width and material of the transformer are involved in the design of safety regulations need special attention

The width of the wall tape: generally need to be as high as

the height of the winding winding, to prevent the copper wire stacked on the false wall when winding, but if the core is difficult to pack sometimes about 1/2-3/4 of the height, but the winding is not stacked on the false wall as the principle.

Tips: Sometimes, if the thickness of the inlet and outlet line is affected by the casing, the method of skipping the outlet line can be adopted. At this time, special attention should be paid to the position of the casing, and there must be enough safe distance (deep into the width of the false wall).

This point must be deep into the false wall sometimes because of the large gap of the false wall or copper foil and M/F and around, there is no obvious discrimination whether deep into the false wall or line M/T must be selected and M/T the same width of the safety bar, each piece of measurement.
